- CD Nominal Diameter: 90 mm
- Nominal Impedance: 8 Ω
- CD Rated Power AES: 30 W
- CD Continuous Program Power: 60 W
- Sensitivity @ 1W/1m: 105.7 dB
- Voice Coil Diameter: 38 mm (1.5″)
- Voice Coil Winding Depth: 2.5 mm
- Magnetic Gap Depth: 2.5 mm
- Flux Density: 1.64 T
- DC Resistance: 6.0 Ω
- Resonance Frequency: 1.0 kHz
- Magnet Weight: 405 g
- Net Weight: 0.93 Kg
- Recommended Crossover Frequency: 2.0 kHz
- Throat Diameter: 25.4 mm (1″)
